Implementación MIDI
OMNI OFF (Controller number 124)
Status 2nd byte
BnH 7CH
n = MIDI channel number:0 H - FH (ch.1 - ch.16)
* The same processing will be carried out as when All Notes Off is received.
OMNI ON (Controller number 125)
Status 2nd byte
BnH 7DH
n = MIDI channel number: 0H - FH (ch.1 - ch.16)
* The same processing will be carried out as when All Notes Off is received.
MONO (Controller number 126)
Status 2nd byte
BnH 7EH
n = MIDI channel number: 0H - FH (ch.1 - ch.16)
mm = mono number: 00H - 10H (0 - 16)
* The same processing will be carried out as when All Sound Off or All Notes Off is
received.
POLY (Controller number 127)
Status 2nd byte
BnH 7FH
n = MIDI channel number: 0H - FH (ch.1 - ch.16)
* The same processing will be carried out as when All Sound Off or All Notes Off is
received.
Mensaje a Tiempo Real del Sistema
* Following System Realtime Messages cannot be recorded in recording mode.
Reloj de Temporización
Status
F8H
* Recognized only when the [SYSTEM]-(UTILITY) Seq Sync is set to "Ext".
Inicio
Status
FAH
* Recognized only when the [SYSTEM]-(UTILITY) Seq Sync is set to "Ext" or "Remote".
Continuación
Status
FBH
* Recognized only when the [SYSTEM]-(UTILITY) Seq Sync is set to "Ext" or "Remote".
Detención
Status
FCH
* Recognized only when the [SYSTEM]-(UTILITY) Seq Sync is set to "Ext" or "Remote".
Sensibilidad Activa
Status
FEH
* When Active Sensing is received, the unit will begin monitoring the intervals of all
further messages. While monitoring, if the interval between messages exceeds about 420
ms, the same processing will be carried out as when All Sounds Off, All Notes Off and
Reset All Controllers are received, and message interval monitoring will be halted.
94
3rd byte
00H
3rd byte
00H
3rd byte
mmH
3rd byte
00H
Mensaje Exclusivo del Sistema
* Following System Exclusive Messages cannot be recorded.
Status Data byte
F0H iiH, ddH, ......, eeH
F0H: System Exclusive Message status
ii = ID number: an ID number (manufacturer ID) to indicate the manufacturer whose
Exclusive message this is. Roland's manufacturer ID is 41H.
ID numbers 7EH and 7FH are extensions of the MIDI standard;
Universal Non-realtime Messages (7EH) and Universal Realtime
Messages (7FH).
dd,..., ee = data: 00H - 7FH (0 - 127)
F7H: EOX (End Of Exclusive)
The System Exclusive Messages received by the normal mode of HPD-15 are; Universal
Non-realtime System Exclusive Messages, Data Requests (RQ1), and Data Set (DT1).
Mensajes Universales Exclusivos del Sistema No a
Tiempo Real
Identity Request
Status Data byte
F0H 7EH, dev, 06H, 01H
Byte Explanation
F0H Exclusive status
7EH ID number (universal non-realtime message)
dev Device ID (dev:00H - 1FH (1 - 32) Initial value is 10H (17))
06H, 01H Identity request
F7H EOX (End Of Exclusive)
* Even if the Device ID is 7FH (Broadcast), Identity reply message will be transmitted.
* When Identity Request is received, Identity reply message will be transmitted (Page 98).
Transmisión de información
HPD-15 can transmit and receive the various parameters using System Exclusive messages.
The exclusive message of HPD-15's data has a model ID of 00H 2EH and a device ID of 10H
(17). Device ID can be changed in HPD-15.
Request data 1 RQ1 (11H)
This message requests the other device to send data. The Address and Size determine the
type and amount of data to be sent.
When a Data Request message is received, if the device is ready to transmit data and if the
address and size are appropriate, the requested data will be transmitted as a "Data Set 1
(DT1)" message. If not, nothing will be transmitted.
Status Data byte
F0H 41H, dev, 00H, 2EH, 11H, aaH, bbH,
ccH, ddH, ssH, ttH, uuH, vvH, sum
Byte Explanation
F0H Exclusive status
41H ID number (Roland)
dev Device ID (dev: 00H - 1FH (1 - 32) Initial value is 10H (17))
00H 2EH Model ID (HPD-15)
11H Command ID (RQ1)
aaH Address MSB: upper byte of the starting address of the requested data
bbH Address 2nd: 2nd byte of the starting address of the requested data
ccH Address 3rd: 3rd byte of the starting address of the requested data
ddH Address LSB: lower byte of the starting address of the requested data
ssH Size MSB
ttH Size 2nd
uuH Size 3rd
vvH Size LSB
sum Checksum
F7H EOX (End Of Exclusive)
* The amount of data that can be transmitted at once time will depend on the type of data,
and data must be requested using a specific starting address and size. Refer to the
Address and Size listed in "Parameter Dump Request" (Page 102).
* Regarding the checksum please refer to Page 103.
Status
F7H
Status
F7H
Status
F7H
