How to Operate Your Ceiling Fan (Continued)
5. Remote functions: (Figure 5)
• Indicator LED light: fan speed
• button: Turns fan off.
• Fan Speed:
Turns fan on and turns speed up.
Turns fan on and turns speed down.
• Light button: Turn ON\OFF the light.
Press to turn on the light and hold to dim or
brighten light to desired level, then release.
Press this button to switch color temperature
when the light is on.
• Sleep Timer:
Tap and the fan and light will turn off after
1 hour.
Tap and the fan and light will turn off after
3 hours.
Tap and the fan and light will turn off after
6 hours.
6. If airflow is desired in the opposite direction, turn
the fan off and wait for the blades to stop turning.
Then slide the reverse switch on top of motor
assembly to the opposite position and turn fan on
again. (Figure 6 )
Reverse Switch Information
Season Rotation Direction
Summer Counterclockwise
Winter Clockwise

How to Install Your Remote Control

1. Installing Wall Holder: (Figure 1)
Attach wall holder using the two provided screws.
Switch Position
Left
Right
13
Figure 5
Reverse
Switch
Figure 6
Figure 1
Screws (2)
Wall Holder
