Fully illustrated step by step instructions are
downloadable on www.saniflo.co.uk
1
DESCRIPTION
SANICOMPACT /SANICERAMIC
®
with an integral pump/macerator.SANICOMPACT
SANICERAMIC is for domestic use.
®
Installed and used correctly, SANICOMPACT
will give consistent and reliable service.
SANICERAMIC
®
Please note the following warning signs:
" " Possible danger to personnel,
" " Warning of possible electrical hazard.
"WARNING" This is a general warning that failure to
follow instructions could result in poor functioning
of the unit.
OPERATION
SANICOMPACT /SANICERAMIC
®
tronic program. It has 2 functions:
• It will macerate the WC waste and pump it away
to the drain: a push of the button will set in motion
the 25 second cycle to the above.
• It will pump away the waste water from a washandbasin.
In this case, the motor will activate automatically when
the water enters.
2
LIST OF ACCESSORIES INCLUDED
3
DIMENSIONS
4

TECHNICAL DATA

discharge of a WC
Applications
discharge of a washbasin (option)
Type
Maximum Vertical Pumping
Voltage
Frequency
Normal Power Rating
Maximum current consumption
Electric Class
Degree of protection
Maximum water temperature
Net Weight C3
C5
C6
C43/SANICERAMIC 1
C48
C4
Only installations conforming to the above
WARNING:
specifications are acceptable.
PERFORMANCE CURVE
6 INSTALLATION
ATTACHING THE TOILET TO THE FLOOR
6a
Find a suitable location, place the SANICOMPACT
SANICERAMIC on the floor. Mark the perimeter of the
®
bowl on the floor and mark where the bracket screws will
be, (rear screw holes). Remove the bowl. Measure 5/8 inch
(15 mm) inwards from the line and mount the L-brackets on
the floor.
Note: To reduce noise level when the toilet is installed on a
hard floor, you may want to insert an insulating material
between the floor and the bowl.
is a WC specially designed
®
/
®
/
®
is operated by an elec-
®
CS40 or CLV50
3 m
220-240 V
50 Hz
800 W
2,6 A or 4,3 A
I
IP44
35°C
28,6 Kg
29,0 Kg
26,5 Kg
23,2 Kg
25,4 Kg
22,0 Kg
/
®
6b CONNECTION OF THE DISCHARGE
1 - Push the plastic insert and rubber non return flap
down into the rubber discharge pipe until it is flush with
the lip.
2 - Point the non-return valve flap so that it opens in the
direction of flow of the discharge. Now place the
discharge elbow over the flap assembly.
3 - Secure the base of the elbow
and non-return valve flap assembly with the jubilee clip
provided .
C
Connect the 32 mm discharge pipework to the other
end and secure with jubilee clip
4 - Warning: Ensure that you do not twist the discharge
pipework inside the unit.
5 - Warning: The horizontal portion of the discharge pipe
should be installed in a gravity flow, (1/4 inch to 1 foot).
Avoid any low parts in the discharge pipe.
6 - Warning: Protect pipes against freezing with appropriate
insulation. If the toilet is installed in an unheated location
during freezing periods protect it as follows:
• Shut off the water supply,
• Activate one cycle without water,
• Pour antifreeze in the bowl (2 litres),
• Flush the toilet.
7 - Warning: Any bends in the discharge pipe run should be
smooth radius bends. If using plastic pipe two 45 degree
offsets can be used to form a smooth bend.
8 - Note: We would recommend that a drain-off point is
installed to allow the discharge pipework to be drained
down before any service work.
9 - Note: To avoid siphoning, install a an anti-siphon valve
at the high point of the installation.
CONNECTION OF A WASH BASIN (OPTION)
6c
If your SANICOMPACT /SANICERAMIC
®
receive the waste water from a wash basin
(Warning: special order).
Make the connection as shown on fig.
6d CONNECTION TO THE WATER SUPPLY
Connect the water supply hose to a shut off valve
Caution: The quality of the rinsing of the bowl depends on
the water pressure.
WARNING: for a correct rinsing, the water pressure should
be at least 25 PSI (1,7 bars).
Note: In an area where water is not pure (dirty, sandy), we
advise you to add a filter between the shut off valve and the
toilet to prevent clogging of the solenoid valve.
6e CONNECTION TO THE ELECTRICAL SUPPLY
The electrical installation should be carried by a
qualified person.
All wiring must conform to BS7671, 1992 requirements for
electrical installation. The unit requires a 220/240 V single
phase AC 50 Hz supply (UK specification). Do not connect
the unit to a conventional plug and socket. The unit should
be connected to a fully earthed electrical supply (class 1).
It must be wired into an unswitched fused fixed wiring
connector protected by a 5 amp fuse and a residual current
detector (30 mA). This connection must be used exclusively
for supplying the unit.
The wires in the mains lead are coloured in accordance
with the following code:
Brown –
Blue –
Green/Yellow –
H
to the discharge pipe
I
.
D
is equiped to
®
to .
1 3
Live
Neutral
Earth
