How to Assemble
1. Slide blades through slots in the motor assembly
with blade holes positioned over threaded posts. Make
sure the bottom edge of the blades are fully seated
against the flywheel of motor assembly. Install and
tighten the washer head screws with fiber washers
to secure the blades to the motor assembly. (Figure 1)
NOTE:
Periodically check blade hardware and
resecure if necessary.
WARNING
!
To reduce the risk of personal injury, do not bend the
blade when installing, balancing the blades or
cleaning the fan. Do not insert foreign objects in
between the rotating blades.
CAUTION
To reduce the risk of electric shock, disconnect the
electrical supply circult to the fan before installing
light kit.
Your
Ceiling Fan Blades
HARDWARE USED:
3/16 -24
Washer Head
Screw
FIBER WASHER
12
Motor Assembly
(3 per assembly)
Blade
Figure 1
x 15
x 15
