BE Power Equipment B4014VTBA Manual Del Operador página 14

1.
2.
5.
Spray Gun - Controls the application of water onto the cleaning surface with a trigger
1.
device. Includes trigger lock. Allows you to switch between various spray nozzles.
High-Pressure Hose - Designed to withstand the pressure created by the pump.
2.
Fuel Tank - Fill tank with regular, unleaded fuel. Always leave room for fuel expansion.
3.
Unloader - Pressure is preset from the factory.
4.
Pump - Develops high-pressure. Connect the garden hose to the inlet of the water
5.
pump, and connect the high-pressure hose to the outlet. Connections vary by model.
Detergent Siphoning Hose - Used to draw detergent into the low-pressure stream.
6.
Muffler/Exhaust - Reduces noise of the engine and expels heat.
7.
Air Filter - Protects engine by filtering dust and debris out of the intake air.
8.
Spray Nozzles - 0°, 15°, 40° and Detergent: for various cleaning applications.
9.
14
3.
4.
COMPONENT DIAGRAMS
www.bepowerequipment.com
9.
8.
7.
6.
