Delivery contents

Fig. 2: Delivery contents
1 Product
2 Bag with installation materials (screws, dowels,
sealing plugs)
3 6 x membrane glands
4 Operating and installation manual
5 Additional documents:
n "DIP switch" supplement
n Drilling template
n Circuit diagram
n Test certificate
6
1 2
3
3.4

Product structure

Exterior view
4
4
5
5
Fig. 3: Exterior view
1 Top section of housing
2 Charging point marking according to EN 17186
3 LED information panel
4 Bottom section of housing
5 Charging cable
1
2
3
