Figure 5, joystick

6. Overview of the different motions

The directions of motion in this manual are described as seen from
behind the robot�
Forward/Backward
Move joystick shaft forwards/
backwards, while pressing buttons 1
and 2 simultaneously.
Telescope out/in
The telescope can run out of its
parked position 0 to position 425.
Move joystick shaft forwards/
backwards, while pressing button 1.
