TCP/IP settings
Select the type of LIS connection used. The cor-
rect settings should be asked from an administra-
tive person responsible for the LIS-system.
WLAN settings
Select the type of WLAN connection used by
choosing Scan or Manual setup.
Use only an adapter supplied by Aidian. You can
insert the adapter to any free USB port.
Note: Use only the strongest available security
policy.
Character encoding
Select the type of character encoding used for
LIS01-A2 protocol.

Factory reset

The factory settings of the user interface can be
restored. The factory reset deletes all profiles and
results, and empties the error log.

Manufacturer settings

The Manufacturer settings section of the menu
system is only for the manufacturer's use.

Profiles

User-adjusted settings can be saved as profiles
for later use. Up to four user profiles can be saved
in the instrument's memory.
Creating a profile
When the instrument has been set to work as de-
sired, the settings can be saved as a profile:
1.
Choose Save as profile.
2. Select a profile (you may choose a new profile).
3. Give the profile a name.
4.
Choose OK.
Applying a profile
Choose Apply a profile. Select the desired profile.
5 PERFORMANCE
CHARACTERISTICS AND
SPECIFICATIONS

Declaration of Conformity

QuikRead go Instrument complies with the elec-
tromagnetic emission and immunity requirements
described in the standard IEC 61326-2-6. The in-
strument fulfills the FCC class A requirements.

Technical specification

The instrument has a pre-programmed micro-
processor that controls the assay steps and data
processing. Test identification, timing, and the cali-
bration curve are stored in a barcode on each cu-
vette. Once activated by the cuvette label, the mi-
croprocessor controls and guides all steps in the
assay and converts the absorbance values from
the samples into concentration units.

PERFORMANCE CHARACTERISTICS AND SPECIFICATIONS

Photometer

QuikRead go Instrument photometer features
a measurement well, three LEDs, and light-de-
tectors. The photometer has been designed and
calibrated for both photometric and turbidimetric
measurements.

Touchscreen display

The user interface consists of an easy-to-use
touchscreen display. It is used by means of touch-
sensitive buttons presented on the screen. It also
provides the user with messages and prompts for
performing each step in the assay, and it reports
the test results and any error messages.
4-wire resistive
Display size: 116.16 × 87.12 mm
Pixels: 640 × 480

Dimensions and power requirements

Weight: 1.7 kg without power supply
Size: 27 x 15.5 x 14.5 cm
Power requirements:
100–240 V AC
50–60 Hz power supply or battery pack
Max 26 W power consumption
Power supply: supplied with the instrument
Battery pack: supplied separately (only a bat-
tery pack supplied for QuikRead go Instru-
ment use can be used)

Instrument software

New software can be uploaded via USB. Ask your
local supplier for more details.
25
