Power cable and battery pack

QuikRead go Instrument can be used with either
the power-supply cable or an optional battery
pack.
The battery pack is charged automatically when
the power cable is plugged in.
USB
RJ-45
Consult instructions
for use
Constant force,
motion or flow
On-Off switch
Image 6
Symbols on QuikRead go Instrument

Connectors and cables

On the back of the instrument are five connection
slots, with symbols describing their use. One USB
port can be found on the right side of the instru-
ment. All of the symbols are described in Image 6.
The RJ45 connector can be used for serial and
LAN connections.
Image 7
Connection of the power supply cable
INSTALLATION PROCEDURES AND REQUIREMENTS

Plugging in the power supply cable

Plug in the power-supply cable, using the marked
connection at the back of the instrument (see
Image 7). Plug in the other end of the cable to a
power outlet.
