Instrument identifier

Each QuikRead go Instrument has its own serial
number, which can be found on the label on the
bottom of the instrument.

Memory

QuikRead go Instrument has an internal memory
for result history. See the section "Results".

Power supply

The instrument is powered by a power supply
supplied with the instrument. Additionally, the
instrument can use a battery pack as a power
source. An internal switch within the cable con-
nector switches the instrument automatically from
battery-powered to mains current use. For instruc-
tions on installing a battery pack, see the section
"Inserting a battery pack."

Serial connection

The RJ45 socket can be used for a serial-type
connection with a special cable. Specifications for
wiring of the cable can be found on the website
quikread.com.

LAN connection

The RJ45 interface supports a 10BASE[1]
T/100BASE-TX/1000BASE-TX Ethernet connec-
tion. Cat 5 / Cat 5e UTP (unshielded twisted pair)
cable should be used.
Power over Ethernet (PoE) is not supported.
WLAN connection
An external WLAN USB storage is needed. Use
only an adapter supplied by Aidian.
26
PERFORMANCE CHARACTERISTICS AND SPECIFICATIONS
PROFILE
Quality control
Settings

USB connection

The instrument has three A-type USB connectors.
These connectors can be used for the printer, bar-
code reader and memory stick. The instrument
can be connected as a virtual com-port to a PC or
computer via a B-type USB connector.
LIS ON
Measure
Results
Profiles
Image 20
Start a basic measurement by choosing Measure
in the main menu
10:30
