ENGLISH
M: Display (Fig. 14)
1. Temperature indicator
When a wash cycle is selected, the default temperature value of this programme will
appear on the display, with the temperature indicator light illuminated.
You can change the temperature value by pressing the TEMP button. If "- -" is shown on the
display, it means that the washer dryer uses cold water only (the internal heating element
for heating water would not be available in this programme).
2. Rotational speed indicator rpm
When a wash cycle is selected, the default spin speed of this programme will appear on
the display, with the spin speed indicator light illuminated.
You can change the spin speed value by pressing the "SPEED" button. If "- -" is shown on
the display, it means that the washer dryer does not spin after the final draining process in
this programme.
3. Door lock indicator
The lit symbol indicates that the door is locked. To avoid any damage, wait until the icon
turns off before opening the door.
To open the door while a wash cycle is in progress, press the START/PAUSE button. If the
Door Lock icon is off, the door can be opened.
NOTE: for safety reasons it is not always possible to open the door once the wash cycle
has started.
4. Child-lock indicator
The lit icon means that the function is activated, the buttons on the control panel will be
locked (except the OFF position of the selector).
5. Delay end indicator
The lit icon means that the function is activated. The countdown to the end of the selected
wash cycle will appear on the digital display.
6. One touch indicator
The lit icon means that the "M-Smart" washing programme has been selected.
There are 3 ways to set this wash programme.
7. Drying function indicator
When the icon lights up, it means that the drying function has been set or the drying cycle
is running.
