Test the equipment's settings on a scrap pie-
ce of material.
•
Let the equipment reach full speed. Only then
should you lower the cutter to its working
height and lock the equipment with the clamp
lever (19).
Cordless palm router
•
To avoid damage to the router, make sure
there are no foreign objects attached to the
workpiece.
•
Hold the router's handle.
•
Place the cordless palm router on the workpi-
ece.
•
Set the routing depth as explained in section
5.6.
•
Select the speed as explained in section 6.2
and switch on the equipment (see section
6.1)
•
Test the equipment's settings on a scrap pie-
ce of material.
•
Let the equipment reach full speed.
Cutting direction: The cutting tool turns clock-
wise. To avoid accidents you must always cut
against the direction in which the tool turns (Fig.
18).
Feed speed: It is very important to machine the
workpiece at the correct feed speed. We recom-
mend that before you machine the actual workpi-
ece, you carry out several trial cuts on a scrapped
piece of the same material. This is the easiest way
to fi nd the best working speed for the workpiece.
Feed speed too low:
The cutter might overheat. If you are cutting in-
fl ammable material such as wood, the workpiece
might ignite.
Feed speed too high:
The cutter might become damaged. Cutting quali-
ty: Rough and uneven.
Allow the cutter to come to a complete standstill
before removing the workpiece or putting down
the router.
6.5 Step-by-step routing
Step-by-step routing makes sense when proces-
sing hard material and performing deep cuts.
•
Adjust the end stops as explained in section
5.8.
•
To carry out a routing job in several steps you
must then set the routing depth as explained
in section 6.3 before turning the end stop
Anl_TP-RO_18_Li_BL_EX_ZA_SPK7.indb 17
Anl_TP-RO_18_Li_BL_EX_ZA_SPK7.indb 17
GB
(13) so that the depth stop (14) lies above the
highest end stop (13).
•
Now perform a cut in this setting. When the
first cut is completed, set the end stop (13) so
that the depth stop (14) lies above the middle
end stop. Now perform a cut in this setting as
well.
•
Finally, set the lowest end stop and complete
the cutting.
6.6 Cutting circles with the compass point
(33)
Proceed as follows to cut circles around a center-
point:
•
Fit and adjust the compass point (33) as exp-
lained in section 5.4.
•
Place the compass point (33) on the center-
point of the circle you want to cut and press it
in place.
•
Perform the cut as described in section 6.4.
6.7 Making cuts with the parallel stop (34)
Proceed as follows to cut along a straight outer
edge of a workpiece:
•
Fit the parallel stop (34) as explained in sec-
tion 5.3.
•
Move the parallel stop (34) along the outer
edge of the workpiece.
•
Perform the cut as explained in section 6.4.
6.8 Making cuts freehand
The cordless router/palm router can also be used
without any guides. You can use it freehand on
creative jobs such as the production of lettering.
•
Use a very flat cutter setting for this purpose!
•
Check the direction in which the cutter is tur-
ning while you machine the workpiece (Fig.
18).
6.9 Cutting shapes and edges (Fig. 19)
•
Special cutters with a guide ring can be used
for cutting shapes (a) and edges (b).
•
Fit the cutter.
•
Carefully move the machine against the work-
piece.
•
Using gentle pressure, move the guide jour-
nal or ball bearing (c) along the workpiece.
Cordless palm router
With the help of the routing guide (32) you
can also perform edge cuts.
•
Fit the routing guide (32) as explained in Fig.
5.9.
•
Place the cordless palm router on the workpi-
ece and adjust the height of the routing guide
- 17 -
