iV. 6. technical characteristics
Dimensions: D x W x H: 29.2 x 35.8 x 52.8 cm (11.5 x 14.1 x 20.8 in).
Weight: 13.6 kg (30 lbs).
Sound level: 40 dBA
Flow values:
1 - 5 l/min.
average oxygen content:
• 90% +5.5%/-3%.
(values at 21°C (69.8ºF) and at an atmospheric pressure of 1013 mbar). Max. flow: 5l/min. The
maximum outlet pressure is 55kPa.
electrical power supply:
• 220 - 240 V - 50 hz europe / 115 V – 60 hz / 220 - 240 V – 60 hz (other
countries, depending on version)
• Use the cable provided, and check that the electrical characteristics of the mains socket used
match those indicated on the manufacturer's plate on the rear panel of the machine.
• Mean power rating: 290 watts
Class II
Type B
1.5 amps (220 - 240 V).
3.0 amps (115 V).
Filters:
Before the oxygen outlet: a product filter < 0.30 µm.
air circulation:
A fan cools the compressor compartment.
environmental limit conditions:
The performances of the device (especially the oxygen concentration) are quoted at 21°C (69.8ºF)
and 1013 mbar. They may change with temperature and altitude.
- The device should preferably be stored and transported in the vertical position.
- The device must only be used in the vertical position.
- Ambient temperature of between 5°C and 40ºC (41ºF and 104ºF) (operation for 115 VAC units).
- Ambient temperature of between 5°C and 35ºC (41ºF and 95ºF) (operation for 220-240 VAC
units).
- Storage temperature range from -20°C to 60°C (-4ºF and 140ºF) .
- Relative humidity up to 95% (non-condensing).
