Specifications
Superstructure
Boom
13,3 m to 68,0 m seven section TWIN-LOCK™ boom.
Maximum tip height 71,0 m.
Boom elevation
1 cylinder with safety valve, boom angle from -1,5° to +83°.
Load moment and independent
anti-two block system
Load moment and independent anti-two block system with audio
visual warning and control lever lock-out. These systems provide
graphic display of boom angle, length, radius, tip height, relative load
moment, maximum permissible load, load indication and warning of
impending two-block condition with lock-out hoist function.
Cab
Aluminium, full vision, tiltable (approx. 20°), safety glass,
adjustable operator's seat with suspension, engine-dependent hot
water heater. Armrest-integrated crane controls. Ergonomically
arranged instrumentation and crane operating controls.
Slewing
3 slewing gears with axial piston motors, planetary gear, automatic
brake with foot operated release switch for free slew.
Counterweight
51 tonnes, consisting of various sections (vehicle width 3,00 m).
Hydraulic removal system.
Engine
Mercedes-Benz OM906LA, diesel, 6 cylinders, water cooled,
turbocharged, 170kW (231 HP) at 2200 rpm. (80/1269 EWG -
fan rigid). Max. torque: 810 Nm at 1200 rpm. Fuel tank capacity:
integrated in carrier fuel reservoir.
Engine emission: EUROMOT / EPA / CARB Tier III (non-road).
4
Hydraulic system
2 separate circuits, 1 axial piston variable displacement pump (load
sensing), with electronic power limiting control and 1 double gear
pump for slewing. Thermostatically controlled oil cooler. Tank
capacity: 916 l.
Control system
Full electronic control of all crane movements using electrical
control levers with automatic reset to zero. Integrated with the
LMI and engine management system by CAN-BUS. ECOS
system with graphic display.
Hoist
Axial piston motor with planetary gear and brake. Drum rotation
indicator.
Electrical system
Three-phase alternator 28 V/80 A, 2 batteries 12 V/170 Ah.
*Optional equipment
• Bi-fold swingaway, 12/21 m - with hydraulic offset and luffing
under load (5° - 40°), controlled from the crane cab.
• Lattice extension, 29/37 m - includes 8 m fixed, non-offsettable
sections plus 12/21 m swingaway (see above).
• Additional 20/26 tonnes counterweight (total counterweight
71/77 tonnes).
• Auxiliary hoist.
• Engine-independent hot water heater, with engine pre-heater.
*Further optional equipment upon request.
