allows for changing the timing of the B3, B5 and B7 steps
that are in sequence during a regeneration cycle (see table 3).
In the beginning, selecting "NO" is advisable so as to make
the softener work according to standard timing. At a later
stage, such datum can be changed only if needed. By se-
lecting "NO" and pressing
be continued. By selecting "YES" and pressing
min sec" will be viewed on the display. Values can be incre-
ased or decreased by pressing the
selecting to confirm changes. You can then shift to adjust
OK
changes for the B5 and B7 steps.
CHART 3 : Min and max step duration:
5.6 RESIN DISINFECTION AND SALT ALARM
FASE
MIN
B3 1
B5 15
B7 0
(MONITORING SALT PRESENCE)
The water softener is provided with a system that disinfects
the resins during regeneration.
This device is inserted in the valve (fig. 10, A). It has two
electrodes which, when coming in contact with salt water,
generate a hypochlorite through electrolysis. The hypochlorite
will come in contact with the resins and disinfect them.
If the electrodes do not find salt water, the electrolysis process
will not take place and the equipment will warn the user throu-
gh a visual and acoustic signal that it is necessary to refill the
salt container.
The salt monitoring is performed during step B5 of the rege-
neration.
To activate the monitoring, when the writing "SALT CHECK"
appears on the display by pressing the
"YES" or "NO".
If you select "NO", salt check will not be performed and no
alarm will be activated (the disinfection process will be per-
formed anyway).
You are now finished with setting and the display will show the
Service mode screen (chapter 5.7).
By selecting "YES", "AUDIBLE ALARM" will be viewed on the
display.
By selecting "YES", salt shortage will also be signaled by an
intermittent buzzer. By selecting "NO", salt shortage will only
be viewed on the display.
By using the + key, you can select your choice. Press
to confirm.
End of settings.
5.7 READING SETTINGS ON THE DISPLAY
Information on how the softener is working and what it is
going to do is viewed on the display.
Two lines are used to view the different messages. The top
line shows current day and time; the bottom line shows the
softener model and the program it is running.
Display version when the softener is set on weekly mode
(paragraph 5.2.1)
12:12 SUNDAY
-05-
In the top line current time and day are visible; in the bottom
line the model -05- (AL5) and some figures are viewed (3∙7).
Instruction Manual AL CRONOMETER
CHRONOMETER
the programming phase can
OK
, "step B3
OK
+ and – keys, and then
RANGE IN MINUTES
MAX
5
50
11
+
key, you can select
3 7
•
They stand for the days of the week in which regeneration
cycles will take place – 1 stands for Monday, 2 stands for
Tuesday, 3 stands for Wednesday, and so on and so forth...
3∙7 means that regenerations will take place on Wednesdays
and on Sundays, that is to say on the third and seventh day
of the week.
Display version when the softener shows days interval
(paragraph 5.2.2)
12:12 SUNDAY
-05- -07 RIG F10
Two lines are used to view the different messages. The top
line shows current day and time; the bottom line shows the
softener model and how many days are to elapse before next
regeneration. -07REG = 7 is regeneration frequency; in thix
case, F10 means that the softener is set so as to carry out a
regeneration cycle every 10 days.
CAUTION: if F00 appears on the display, the softener will
never carry out automatic regeneration; regeneration will only
take place in semi-automatic mode (paragraph 7.1).
5.7.1 READING INSTRUCTIONS ON THE DISPLAY
Irrespective of the actual softener setting, some other fun-
ctions will appear on the display. After the name of the day,
one, two or no star symbol can be viewed.
12:12 SUNDAY
+05+
When no star symbol is visible on the display, salt control is
on. Thanks to this setting, in case of salt shortage, a visual
message will be displayed (red led lights on and the "ADD
SALT" message) just as an audible alarm will be on.
- One single star symbol means that salt control is on, but
it will only be visually signaled by red led lights on and the
"ADD SALT" wording on the display.
- Two star symbols mean that salt control is off and that,
once salt is over, no signal will be visible.
When *R* and (R) are displayed, the softener will carry out the
regeneration cycle on the preset day and time.
When "+08+" is displayed before and after the model type,
the regeneration times with extra-rinse have been changed
(see paragraph 5.5).
OK
5.7.2 READING OF SETTINGS AND ALARMS
When the softener is in service, by pressing
operation and setting data can be viewed.
Softener in chronometric mode on a weekly regeneration
program
+
regeneration starting time is displayed
+ +
week days with "*" mean that, on those days,
regeneration will take palce
+ + +
alarm history press – to see
+ + + +
first installation
Softener in chronometric mode on a regeneration pro-
gram based on the number of days elapsing between
cycles.
+ regeneration starting time is displayed
+ + alarm history press – to see
+ + + first installation
