3.2 T echnical d ata
Dimensions ( approx.): 345x215x135mm
Main s upply v oltage L 1, L 2, L 3, N , P E: forceIQ-­‐ 4 00V, 5 0HZ / f orceIQ-­‐230 2 30V, 5 0Hz.
Fuse p rotection
Voltage
Access i nput
Safety c ircuit / E mergency s top
Input s afety r ail
Relay o utput
Temperature r ange:
Protection
Weight
10A K -­‐ c haracteristic
24V D C, m ax. 3 20mA
24V D C, A ll i nputs m ust b e a bsolutely p otential f ree c onnected.
Minimum d uration o f i nput s ignal c ontrol c ommand > 100ms.
Connect a ll i nputs a bsolutely p otential f ree; a t i nterruption i n
the s ecurity c ircuit, i t i s n ot l onger p ossible o f e lectrical
operation o f t he m otor, e ven i n h old-­‐to-­‐run m ode.
For e lectrical s afety s trips w ith 8 .2kΩ, l oad r esistor a nd f or
dynamic o ptical s ystems.
If u sed a s p ower s witching c ontacts, i t c annot s erve m ore s mall
electric c urrents.
-­‐15°C -­‐ + 50°C
IP 5 4 ( in h ousing)
Ca. 2 .2 k g
