RS01

7-Complete programming

Customized travel programming
N.B. Before starting programming, check the dip switch 2-2 (OFF opening to left, ON opening to right).
- Move the gate to approximately 1 metre from closing.
- Keep button P3 pressed for 4 seconds (the red DL12 LED starts flashing rapidly), release button P3.
- Press the AP/CH button, the gate rests against the mechanical stop on closing, to then start again with opening.
- Before the gate gets to be fully open, press the AP/CH button and the control unit will save the point for starting to slow down when opening
- The gate continues slowing down as far as the mechanical stop, to then restart with closing
- Before the gate gets to be fully closed, press the AP/CH button and the control unit will save the point for starting to slow down when closing
- The gate continues slowing down as far as the mechanical stop, to then restart with opening
- Press the AP/CH button to fix the space for pedestrian opening (when controlling with the Aped input the gate opens by the space set here), the
gate starts closing, as far as the mechanical stop.
- The control unit saves the set travel and the DL12 LED goes out, the procedure for programming the travel is successfully concluded.
Programming or deleting radio controls
Save the remote control button to control the AP/CH input: press the P2 button until the DL12 LED with a green light begins to flash slowly, release the
button and press the button on the remote control to save, the DL12 LED comes on with a green light for 1 second to confirm saving. To save other
radio controls, repeat the above procedure.
Save the remote control button to control the APED input: press the P2 button until the DL12 LED with a green light begins to flash quickly, release
the button and press the button on the remote control to save, the DL12 LED comes on with a green light for 1 second to confirm saving the remote
control button for operating pedestrian opening. To save other radio controls, repeat the above procedure.
To delete a saved remote control: press the P2 button until the DL12 LED with a green light begins to flash very quickly, release the button and press
the button on the remote control to delete, the DL12 LED comes on with a green light for 1 second to confirm deleting the remote control button. To
save other radio controls, repeat the above procedure.
To delete all the remote controls: cut off the power to the control panel, also disconnect any batteries.
Press and hold down the button P2, reconnect the power supply to the control panel without releasing the button P2 until the DL12 LED goes out
The maximum capacity is 200 radio controls, on reaching the maximum capacity being saved on the remote control (the green DL12 LED flashes), on
pressing the button of the new transmitter to be saved, the green DL12 LED makes 3 quick flashes to indicate the memory is saturated.
N.B. The first saved remote control configures the control panel to accept only remote controls with a rolling code or only remote controls with a fixed
12-bit code.
