10. Close the print cartridge cover.

2.3. Operating Test

After installing the imprinter, test to see if printing can be
performed on the Offline Print Test mode.
1.
While pressing the [Function] button (
the operator panel, switch on the scanner.
Continue pressing on the [Function] button.
2.
Release the [Function] button when the Function
Number Display changes from [P] to [b].
Function
Function Number
Display
[Function] button
3.
Place a blank document on the ADF paper chute.
Use A4 or Letter size paper. If the size is
ATTENTION
smaller than A4 or Letter, printing may not
successfully complete.
Confirm that the Print Cartridge is
positioned within the document width.
4.
Press [Scan] button to test.
Paper will feed into the ADF, and the Imprinter will
print out the Print Test Characters starting at 5mm
from the paper's edge.
8 |
or
) on
Send to
Scan
Function
Function
HINT
Print test patterns
Test pattern 1 (Horizontal):
ABCDEFGHIJKLMNOPQRSTUVWXYZ[\]^_`00000000
Test pattern 2 (Horizontal):
abcdefghijklmnopqrstuvwxyz{|}~ 00000000
Test pattern 3 (Horizontal):
!"#$%&()*+,-./0123456789:;<=>?@00000000
Test pattern 4(Vertical):
ABCDEFGHIJKLMNOPQRSTUVWXYZ[\]^_`00000000
Test pattern 5 (Vertical):
abcdefghijklmnopqrstuvwxyz{|}~ 00000000
Test pattern 6 (Vertical):
!"#$%&()*+,-./0123456789:;<=>?@00000000
When multiple sheets of documents are placed in
the ADF, the Test Print repeats patterns from 1
through 6.
The numbering data portion "00000000" changes
from 0 (Zero) with increment of 1(one).
(One test pattern is printed at a time. Press the
[Scan] button to continue printing the next test
pattern.)
Print Test Sample
5.
To stop Offline Print test mode, turn off the
Scanner.
5mm
