1. Description
The soldering Station WTCP 51 is best suited for soldering electrically or thermally
sensitive electronic components. Temperature regulation is carried out using the
WELLER Magnastat principle.
The permanent magnet is attracted to the ferromagnetic temperature sensor when
the tip is cold. This causes the switch to switch on. As the sensor approaches the
Curie-point, it loses its ferromagnetic properties and can no longer hold the
permanent magnet. The magnet releases causing the switch to switch off, thereby
interrupting the feed to the heating element. When the tip cools, the temperature
sensor attracts the permanent magnet again and restores the current feed. There is
little deviation between different temperature sensors (Magnestats) and they are not
subject to wear due to ageing or material fatigue. An addition feature of this
arrangement is that the soldering iron is switched off when changing tips. The
heating element cannot burn out from use without a soldering tip.
Picture: Weller Magnastat system, see page 46
Selection of the correct working temperature is carried out by simply selecting the
temperature coded soldering tip. The WELLER "Longlife" soldering tips are available
in the temperatures 260°C, 310°C, 370°C, 425°C and 480°C. The lifetime of the
WELLER "Longlife" soldering tip is lengthened substantially by the electroplated
finish on the copper core. There are 22 different soldering tip forms to choose from.
You can choose the optimal tip from one of these.
The Magnastat soldering iron TCP-S* is electrically isolated from mains and
operates with a protective low voltage of 24V AC or DC. The soldering iron comes
standard with a temperature resistant silicon cord and a WELLER "Longlife" PT-B7
soldering tip.
* Information contained in the Operation Manuals of any other connected WELLER
tools should be observed in addition to the information contained in this Operation
Manual.
PK Elektronik Vertriebs GmbH, Ellmendinger Str. 23, 76227 Karlsruhe
Tel.: 0721-43337, Fax: 0721-491292, vertrieb@pkelektronik.com, www.pkelektronik.com

Technical Data

GB
Dimensions L X W X H: 166 X 115 X 101
Mains voltage (3): 230 V (240V, 120V) 50(60) Hz
Heating voltage: 24V 50(60) Hz
Soldering iron power: max. 50W at 24V
Mains fuse (4). T0.315 A
Regulation: 2-point regulation with temperature sensor

2. Commissioning

Fasten the holder spring with funnel to the foot plate of the soldering iron holder (see
exploded view) and soak the cleaning sponge with water. Place the soldering iron into
the safety support rack. Insert the soldering iron plug into the 3-channel connection
socket (2) of the control unit and lock it. Connect the control unit to mains (3). Be
sure to check for the correct voltage. Switch on the unit at the mains switch (1).
When using a tip for the first time, tin the end of the soldering tip with solder. This
removes any layers of oxidation and contaminants from the soldering tip.

3. Potential equalisation

The soldering tip is connected directly to the mains earth via the electrical cable
(hard earthing).

4. Working recommendations

Always be sure that the soldering tip is properly tinned during pauses in soldering
and when replacing the soldering iron into the holder. Don't use aggressive fluxing
agents.
Any mechanical treatment of the soldering tip destroys the electro-plated protective
coating of the soldering tip and decreases its lifetime.
Do not immediately run the heating element along iron or expose it to an alternating
electrical field. This can influence the regulation system.
When soldering and desoldering, take into consideration the soldering instructions
of the components, particularly their temperature limits.
