Contents
Safety instructions
Correct use
Unpacking
Useful facts
Drive
Gear speed change
Motor circuit breaker
Speed display
Commisioning
Switching on the machine
Output shaft
Maintenace and cleaning
Technical data
Accesories
Guarantee
Permitted IKA stirrer tools
Assiciated standards and regulations
Spare parts list
Spare parts diagram

Safety instructiones

Never operate the equipment with the stirrer tools rotating
freely. Ensure that parts of the body, hair or items of clothing
cannot be trapped by the rotating parts. Pay attention when
setting the speed to any imbalance of the stirrer tools and
possible spraying of the medium to be stirred. Use a stirrer shaft
protection device!The equipment is not suitable for manual ope-
ration. Please follow the relevant safety instructions and guideli-
nes, and occupational health and safety regulations for use in the
laboratory.
10
Avoid knocks and impacts on the lower end of the shaft and the
chuck gear teeth. Even minor, invisible damage can lead to im-
balance and uneven shaft action. Careful handling guarantees
Page
safe working and the long life of the equipment.
Imbalance of the output shaft, the chuck and in particular the
10
11 stirring tools can lead to uncontrolled resonant vibrational
11 behaviour of the equipment and the whole assembly. Glass
apparatus and stirrer containers can be damaged or shattered by
11
11 this. It can cause injury to the operator, as can the rotating stirring
12 tool. If vibration of the equipment is noticed, the speed must be
reduced immediately in all cases until no more vibration occurs.
12
12 In this case exchange the stirring tool for one without imbalance
12 or remedy the cause of the imbalance.
13
Operating with a freely rotating shaft end is dangerous. Therefore
13
for safety reasons the stirrer tool is permitted to project over the
13
upper edge of the housing only when the machine is not running.
14
The unit must be switched off before changing to another gear
14
speed, otherwise the toothed gears in the reduction stage will be
14
damaged.
15
15
The machine may only be opened by trained specialists - even
78
during repairs. The machine is to be unplugged from the mains
79
before opening. Live parts inside the machine may still be live for
some time after unplugging from the mains.
The high torque developed by the RW 28 basic requires particular
care in the choice of stand, cross sleeve and anti-rotation element
for the stirring bowl.
NOTE! Covering or parts that are capable of being removed from
the unit without accessory equipment have to be
reattached to the unit for safe operation in order to
prevent, for example, the ingress of fluids, foreign
matter, etc.
The agitated vessels used for stirring have to be secured.
RW280597EU
