EverFlo / EverFlo Q User Manual

Symbols Glossary

Symbol Title and Meaning
Refer to the instruction manual
To signify that the instruction manual must be read.
Prescription device
Caution: U. S. federal law restricts this device to sale by or on the order of a
physician.
Type BF applied part
To identify a type BF applied part complying with IEC 60601-1.
Class II equipment (Double Insulated)
To identify equipment meeting the safety requirements specified for Class II
equipment.
No smoking
To prohibit smoking.
No open flame
To prohibit smoking and all forms of open flame.
No oil or grease
Do not disassemble
Alarm
Indicates an alarm condition.
AC power (Alternating current)
Indicates on the rating plate that the equipment is suitable for alternating
current only; to identify relevant terminals.
Catalogue number
Indicates the manufacturer's catalogue number so the medical device can
be identified.
Serial number
Identifies the manufacturer's serial number for the medical device.
On (Power)
Indicates connection to the mains.
2
Reference
IEC 60878
ISO 7010-M002
__
IEC 60878
IEC 60417-5333
IEC 60417-5134
IEC 60878
ISO 7010-P002
IEC 60878
ISO 7010-P003
__
__
IEC 60878
IEC 60417-5307
IEC 60417-5032
IEC 60878
ISO 7000-2493
Symbol 5.1.6, ISO 15223-1
IEC 60878
ISO 7000-2498
Symbol 5.1.7, ISO 15223-1
IEC 60878
IEC 60417-5007
