Symbol Title and Meaning
Off
Indicates disconnection from the mains.
IP21
Drip proof equipment
Malfunction, general, failure
Indicates that a failure or other malfunction has occurred.
Compliant with the Waste Electrical and Electronic Equipment/
Restriction of the Use of Certain Hazardous Substances in Electrical and
Electronic Equipment (WEEE/RoHS) recycling directives
Temperature Limit
Indicates the temperature limits to which the medical device can be safely
exposed.
Humidity Limitation
Indicates the range of humidity to which the medical device can be safely
exposed.
Atmospheric Pressure Limitation
Indicates the acceptable upper and lower limits of atmospheric pressure.
Manufacturer
Authorized Representative in the European Community
Indicates the Authorized Representative in the European Community.
Standards Reference
ISO 7000:2014, Graphical symbols for use on equipment – Registered symbols
ISO 7010:2011, Safety colors and safety signs - Registered safety signs
ISO 15223-1:2012, Medical devices—Symbols to be used with medical devices labels - General requirements
IEC 60417:2002 DB, Graphical symbols for use on equipment
IEC/TR 60878:2015, Graphical symbols for electrical equipment in medical practice
IEC 60529:1989, Degrees of protection provided by enclosures (IP Code)
EN 50419:2006, Marking of electrical and electronic equipment in accordance with Article 11(2) of Directive
2002/96/EC (WEEE)
EverFlo / EverFlo Q User Manual
Reference
IEC 60878
IEC 60417-5008
IEC 60529
ISO 7000-1603B
EC Directive 2012/19/EU
EN 50419
IEC 60878
ISO 7000-0632
Symbol 5.3.7, ISO 15223-1
IEC 60878
ISO 7000-2620
Symbol 5.3.8, ISO 15223-1
IEC 60878
ISO 7000-2621
Symbol 5.3.9, ISO 15223-1
IEC 60878
ISO 7000-3082
Symbol 5.1.1, ISO 15223-1
IEC 60878
Symbol 5.1.2, ISO 15223-1
3
