ROBO Compact W600
1 Identification
The MIG/MAG welding torch is used to safely weld low and high-alloy materials.
The torch consists of:
• Torch neck with equipment parts and wear parts
• Cable assembly with equipment and cable support
The MIG/MAG welding torch corresponds to EN 60974-7 and is not a device having its own
functional performance. Arc welding can only be carried out in connection with a welding
power source.
Optionally, the ROBO Compact W600 MIG/MAG welding torch is available as a version with
wire brake.
These operating instructions only describe the MIG/MAG welding torch
ROBO Compact W600. The MIG/MAG welding torch must only be operated using original
ABICOR BINZEL spare parts.
.
1
1 Torch neck
2 Insulating sleeve
Fig. 1 Product overview
BAL.0374.0 • 2019-04-01
2 3
3 Cable support housing, torch-side
4 Cable assembly
5 Cable support housing, machine-side
6 Nameplate, yellow
1 Identification
4
5
6
EN - 3
