Measurements - AND A&D Medical UB-1100BLE Manual De Instrucciones

In-App Mode Measurement
1. Ensure the Bluetooth® function of the mobile device is ON.
2. Open the A&D Connect app. The app will automatically detect the
presence of the monitor.
3. Press the Take Measurement button, followed by the Start button
on the app screen.
User number
4. The C.P.G. indicator will display the correct wrist position briefly.
5. The cuff starts to inflate. It is normal for the cuff to feel tight. The app displays the pressure value once inflation starts.
6. When the measurement is complete, the app and the monitor will display
results similar to the icon on the right.
(Systolic, diastolic and pulse rate will be displayed in rotation.)
Note: Press the start button again to turn the monitor off. The monitor is also
provided with an automatic power shut-off function. Allow at least
one minute between measurements on the same person

Measurements

Username
Monitor Display
Take measurement
.
Icons(Refer to pg.8,21
English 17
App Display
Monitor Display
Result Notification
App Display
For details)
Start
