 Dusts from materials such as lead-containing
coatings, some wood types, minerals and
metal can be harmful to one's health and
cause allergic reactions, lead to respiratory
infections and/or cancer. Materials containing
asbestos may only be worked by specialists.
• As far as possible, use a dust extraction system suita-
ble for the material.
• Provide for good ventilation of the working place.
• It is recommended to wear a P2 filter-class respirator.
Observe the relevant regulations in your country for the
materials to be worked.
 Prevent dust accumulation at the workplace.
Dusts can easily ignite.
 Observe correct mains voltage! The voltage of
the power source must agree with the voltage
specified on the nameplate of the machine.
Power tools marked with 230 V can also be
operated with 220 V.
 To save energy, only switch the power tool on when using it.
 The restarting protection prevents uncon-
trolled starting of the machine after a power
failure. To restart the machine, set the On/Off switch to
the off position, and then switch the power tool on again.
 The contact protector attached to the casing
(see figure 15, page 201) prevents accidental
touching of the saw blade during the working
procedure and may not be removed.
 Before sawing in wood, particle boards, build-
ing materials etc., check for foreign objects,
such as nails, screws, etc. and remove them as
required.
 Plunge cuts may only be applied to soft mate-
rials, such as wood, gypsum board, etc. For
plunge cuts, use only short saw blades.
 The metal overshoe prevents the plastic foot-
plate from being scratched up, especially
when sawing metal.
 Adapt the settings of your power tool to the
respective application. For example, reduce
the stroke rate and orbital action when cutting
metal or for tight curved cuts.
 When working small or thin work pieces,
always use a sturdy support or a saw table
(accessory).
 In extreme conditions, always use dust extrac-
tion as far as possible. Blow out ventilation
slots frequently and install a residual current
device (RCD). When working metals, conductive dust
can settle in the interior of the power tool. The total insula-
tion of the power tool can be impaired.
 Use only original Würth accessories.
Products sold in GB only: Your product is fitted with an
BS 1363/A approved electric plug with internal fuse (ASTA
approved to BS 1362).
If the plug is not suitable for your socket outlets, it should be
cut off and an appropriate plug fitted in its place by an author-
ised customer service agent. The replacement plug should
have the same fuse rating as the original plug.
The severed plug must be disposed of to avoid a possible
shock hazard and should never be inserted into a mains
socket elsewhere.
Products sold in AUS and NZ only: Use a residual cur-
rent device (RCD) with a rated residual current of 30 mA or
less.
Symbols
The following symbols are important for reading and under-
standing the operating instructions. Please take note of the
symbols and their meaning. The correct interpretation of the
symbols will help you to use the machine in a better and safer
manner.
Symbol Meaning
STP 140 EXACT-S: Jigsaw with con-
stant electronic control
Grey-marked area: Handle (insu-
lated gripping surface)
STP 140 EXACT-B: Jigsaw with con-
stant electronic and bow handle
Grey-marked area: Handle (insu-
lated gripping surface)
Read all safety warnings and all
instructions
Before any work on the machine
itself, pull the mains plug from the
socket outlet
Wear protective gloves
Additional information
