40 - COURTESY LIGHT

Put the PROG key in position as shown in the figure below and press
the LEARN button according to the setting for courtesy light.
Once selected, return the PROG switch to the OFF position (all
down) for the control panel to save the configuration.
Below are the connection diagrams:
Connectors of the central
AC NETWORK
AC network
127/220V
ON
1 2 3
LED blinks 1 time Courtesy light
|
DP
4 5 6 7 8
ENGLISH
Lamp
127/220V
