Capacitance measurement
Range
40.00nF
400.0nF
4.000μF
40.00μF
100.0μF
Temperature measurement
-20.0...760.0C
-4.0...1400F
* probe (K type) accuracy not included
Other technical data
a) Measurement category in acc. with EN 61010-1 .................................... III 600V
b) Ingress protection in acc. with EN 60529 ..................................................... IP40
c) Pollution degree ................................................................................................. 2
d) Power supply ............................................................................... one 9V battery
e) Clamp size ............................................................ Opening 30mm (1.2") approx
f) Diode test.......................................................................... I=0.3mA, U
g) Continuity test ................................................. I<05mA, sound signal for R<50Ω
h) Overrange indication ...................................................................... OL displayed
i) Measurements rate.......................................................... 2 per second, nominal
j) Input impedance ...................................................................... 10MΩ (V AC/DC)
k) Display .................................................................................... LCD, 4000 counts
l) Dimensions ............................................................................. 197 x 70 x 40 mm
m) Weigh .......................................................................................................... 183 g
n) Operating temperature .................................................. 5 to 40°C (41 to 104°F)
o) Storage temperature................................................... -20 to 60°C (-4 to 140°F)
p) Operating humidity .............................. max 80% up to 31°C (87°F) decreasing
.......................................................................... linearly to 50% at 40°C (104°F)
q) Storage humidity ......................................................................................... <80%
r) Max. operating altitude ...................................................... 2000meters (7000ft.)
s) Auto OFF .............................................................................. approx. 30 minutes
t) Compliance with the requirements specified in the following normsEN 61010-1
.................................................................................................. EN 61010-2-032
u) Quality standard ................................................................................... ISO 9001
Resolution
0.01nF
0.1nF
0.001μF
0.01μF
0.1μF
Range
CMP-401 – USER MANUAL
Basic uncertainty
 (4 % m.v. + 20 digits)
 (3 % m.v. + 5 digits)
 (4 % m.v. + 10 digits)
Basic uncertainty *
± (3% m.v. + 5C)
± (3% m.v. + 9F)
=1.5V DC
0
53
