Technical Specifications - Slendertone Abs 3 Manual De Instrucciones

T
ECHNICAL SPECIFICATIONS
Caring for your controller:
Your controller should not be allowed to get wet or be left in excessive sun-
light. It may be cleaned using a soft cloth, lightly dampened in soapy water. Do
not allow the interior of your controller to become wet. Do not use detergents,
alcohol, spray aerosols or strong solvents on your controller.
Access to the interior of the controller is not required for maintenance
purposes.
Note: Using leak-proof batteries is advised. You should never leave
the batteries inside your controller if you do not intend to use it for a long pe-
riod of time. If you do, the batteries may leak and damage it. You should be
aware that some batteries sold as 'leak-proof' can still release some
corrosive substances, which may damage your controller. Under no
circumstance should anything other than the correct type of batteries
(1.5V, AAA) be used with your controller. You should only insert the batteries in
the manner specified in this manual.
Disposing of the GelPads and batteries:
Used GelPads and batteries must never be disposed of in a fire but in
accordance with national or state laws governing the disposal of such items.
Note: When the When the symbol is flashing, the stimulus is significantly reduced. The symbol is flashing, the stimulus is significantly reduced.
signal gradually increases to a peak intensity level at the start of the contrac-
tion phase (ie. ramp up) and gradually decreases to nothing at the start of the
relaxation phase (ie. ramp down).
Environmental Specifications:
Temperature: 32 to 95˚F
Operating Range:
Humidity: 20 to 65 % RH
Transport & Temperature: 32 to 131˚F
Humidity: 10 to 90 % RH
Storage Range:
Product Type: 515-US
Intended use: Muscle stimulator
www.slendertone.com
English
Accessories
When ordering new GelPads, you should only use those carrying the
brand. Any others may not be compatible with your product
SLENDERTONE
and could degrade the minimum safety levels.
3 Adhesive GelPads:
SLENDERTONE ABS
• 1 large adhesive GelPad Type 732
• 2 small adhesive GelPads Type 733
3 Belt
SLENDERTONE ABS
Belt Extension
Material fabrics:
Outer material: 100% Nylon
Binding: 82% Nylon, 18% Elastane
Velcro: 100% Nylon
Foam: 100% Polyurethane
Rated Outputs Voltage/Current:
Parameter
Output RMSV
Output RMSA
Output Frequency 45-75Hz.
DC Component: Approx.
Positive Pulse Width: 200–300 µs
Negative Pulse Width: 200–300 µs
Interphase Interval:
500! 1K!
7.1V 13.4V
14.2mA 13.4mA
45-75Hz. 45-75Hz.
0 C 0 C
200–300 µs 200–300 µs
200–300 µs 200–300 µs
100 µs 100 µs
1K5!
13.7V
9.1mA
0 C
100 µs
13
