Transport
Do not pull the device by the hose or mains
cable. Transport the device by the transport
handle [5].
Check the crane hook [14] for secure fastening,
if necessary, attach securely.
Fit the pull-out transport handle:
Position the device on the rear rubber feet.
Undo the transport handle retaining screws.
Pull out the [5] transport handle.
Retighten the retaining screws of the transport
handle.
When transporting, the device can now be pulled
3
by the transport handle.
Operation

Mains supply

Electrical voltage
Only use the device in a dry environ-
¾
ment.
Only operate the device from a
¾
power source that fulfils the follow-
ing requirements: Sockets installed
according to regulations, earthed and
checked, fuse rating according to the
technical data.
Route the mains cable so that it is not
¾
in the way during work and cannot
be damaged.
Check the device is switched off
¾
before plugging the mains plug into
the socket.
Protect the mains cable against heat,
¾
corrosive liquids and sharp edges.
Use an extension lead that has an
¾
adequate cross-section (see technical
data).
Use an extension cable approved for
¾
outside use. Outdoors, use only ap-
proved and correspondingly labelled
extension cable.
Do not switch the compressor off by
¾
pulling out the mains plug, rather
switch off at the On/Off switch.
Always connect an RCD with a
¾
maximum tripping current of 30 mA
upstream.
22
DANGER!
Producing compressed air
Switch the device on at the On/Off switch [10]
and wait until the maximum tank pressure is
reached.
Once the maximum tank pressure is reached, the
3
compressor switches off.
The tank pressure is indicated at the tank pressure
3
gauge [3].
Attention!
The set control pressure must not be higher that the
maximum operating pressure of the connected air
tools!
Set the control pressure at the pressure con-
troller [6].
The current control pressure is indicated at the
3
control pressure gauge [8].
Connect the air hose at the compressed air
connection [9].
Connect the air tool.
You can now work with the air tool.
3
Switching off the device and pull out the mains
plug if the work is completed or is to be inter-
rupted.
Drain the pressure tank condensation daily at the
condensate drain [13].
Fitting the system box (Fig. V-VIII)
Note
All 8.4. system boxes can be fitted on
the cover plate.
Place the box guide edgeways on the adapter
plate and push to the rear.
Close the fasteners by pushing down.
