All TRAPP shredders, single-phase or
✔
three-phase, are assembled with double
voltage motors. They leave factory without
electrical connection to allow the
customer to choose the kind of connection
based on the voltage of their property
power source , (except TRF 400, which
leaves factory with voltage already
selected).
The same is not true for shredders TRP 40,
✔
TRF 60, TRF 70, TRF 80 and TRF 80M,
which are equipped with a 110/220V
voltage selection switch.
✔ To correctly make the connection, see data
shown on the motor plate and the number
printed on the insulation of the wires.
✔ For shredders sold without motor, the
choice of minimum output shall follow the
technical data shown on pg. 40.
Checking:
Before operating the shredder check:
If there are tools or objects on the motor or
✔
on the equipment, mainly inside the grain
funnel or in the green crop feeder.
If there is something obstructing the
✔
motor.
If the rotation direction is correct.
✔
If the voltage of the power source is the
✔
same of that of the shredder.
Motor Installation
Operation Instructions
44
ENGLISH
Attention!
Before making any connections, make
sure power source is disconnected.
1) Make sure the power source where
the shredder will be installed is
compatible with the data shown
on the motor plate.
2) Disconnect the power source to
make motor connections.
3) Make the connections shown
according to the voltage of the
power source.
4) Use insulating tape in the
connections done to protect them.
5) Make sure the connections are
well insulated.
6) Turn on power source and check
the rotation of the shredder.
If there are people or objects near pulleys
✔
and belts.
If the shredder cover is properly closed.
✔
If the counter cutting blade is properly set
✔
and tightened (pg. 48).
Note:
If the equipment is properly prepared, start
the motor, allow it to reach maximum
revolution and start working.
