2. Assembly instruction

2.1 Mounting the front wheels/swivel wheels

2.2 Mounting the rear wheel axle

2.3 Fixing the rear wheels

Step 1:
Place the front wheel on the bracket as shown.
Step 2:
Press the safety button and keep it pressed.
Step 3:
With the safety button pressed down, place the front wheel
onto the holder.
Step 4:
After the wheel is mounted, release the safety button.
5. step:
Repeat the process for the 2nd front wheel.
IMPORTANT NOTE
Please make sure that the wheels are properly locked
before each use.
Step 1:
Position the rear axle as shown
Step 2:
Press the rear wheel axle onto the frame until it
engages.
Step 3:
Please check carefully that the rear wheel axle is
engaged and then firmly connected to the frame.
