Yellow led flashing on
and off every 2 seconds
The filter carries out
backwashing cycles
continuously
Water loss from the filter
drain
Refer to www.acquabrevetti.itweb site for the closest C.A.T. list.

A4 BRAVOMATIC DISPOSAL

Electrical and electronic devices must not be considered household waste.
Consumers must return electronic and electronic devices at the end of their life to recycling/disposal centers.
The crossed-out wheeled bin symbol indicates that the product is subject to the disposal regulations required
by law. The illegal disposal of the product by the user involves the application of administrative penalties.
With the recycling and reuse of the material and other forms of use of obsolete devices, an important
contribution to the protection of the environment can be made. Before proceeding with waste disposal, in any
case contact the Waste Management Service of your Municipality for clarification.

A5 BRAVOMATIC LABELLING

On the upper side of the equipment there is an identification label of the purchased product. In particular the
serial number must be copied on the warranty certificate.
Serial number

A6 EXPLODED VIEW

Production date (month/year)
MAN139 Rev.2
BRAVOMATIC - ENGLISH
Differential blocked
The black central button
placed in the middle of the
carter between two led could
be blocked.
The filter doesn't carry out the
cleaning because it is
mechanically stressed
Differential blocked.
The black button placed in the
center of the cover between
the leds may be blocked
Discharge valve may be
tampered with or blocked
Discharge valve in out of
phase position.
AAA 00123
0X 0Y
Close the main water or the by pass valve
pull the differential feeder little tubes out, vent
or blow with air in order to unblock it.
Verify that the cover doesn't force the black
button placed between the two leds on
manual washing functioning and, in case, fix
it..
Close the main water or put the equipment in
by pass position; contact a C.A.T.
Close the main water or the by pass valve,
pull the differential feeder little tubes out, vent
or blow with air in order to unblock it.
Verify that the cover doesn't force the black
button placed between the two leds on
manual washing functioning and, in case, fix
it.
contact a C.A.T.
contact a C.A.T.
PAG.E-10
