Specifications

EPA / CEPA
The Emission Compliance Period
referred to on the Emissions
Compliance Label indicates the number
of operating hours for which the engine
has been shown to meet Federal
emission requirements.
Category
A = 300 hours
B = 125 hours
C = 50 hours
CARB
The Emission Compliance Period used
on the CARB-Air Index Label indicates
the terms:
Extended = 300 hours
Intermediate = 125 hours
Moderate = 50 hours
Engine
STIHL single cylinder two-stroke engine
TS 700
Displacement: 6.0 cu. in.
(98.5 cm
Cylinder bore: 2.2 in. (56 mm)
Piston stroke: 1.57 in. (40 mm)
TS 700, TS 800
Engine power accord-
ing to ISO 7293:
Idle speed:
Max. spindle speed:
TS 800
Displacement:
Cylinder bore:
Piston stroke:
Engine power accord-
ing to ISO 7293:
Idle speed:
Max. spindle speed:
Ignition system
Electronic magneto ignition
Spark plug
(suppressed):
Electrode gap:
Fuel system
All-position diaphragm carburetor with
integral fuel pump
Fuel tank capacity:
Air filter
Main filter (paper filter) and flocked wire
3)
mesh auxiliary filter
Weight
6.7 hp (5.0 kW)
at 9300 rpm
2200 rpm
without fuel, without abrasive wheel,
5350 rpm
with water attachment
TS 700:
TS 800:
6.0 cu. in.
3)
(98.5 cm
2.2 in. (56 mm)
Abrasive wheels
1.57 in. (40 mm)
6.7 hp (5.0 kW)
The quoted maximum permissible
at 9300 rpm
operating speed of the abrasive wheel
2200 rpm
must be greater than or equal to the
4600 rpm
maximum spindle speed of the cut-off
machine used.
Abrasive wheels (TS 700)
Bosch WSR 6 F,
Outside diameter:
NGK BPMR 7 A
0.02 in. (0.5 mm)
Max. thickness:
Bore diameter/spindle
diameter:
Tightening torque:
Composite resin abrasive wheels
40.6 oz
(1.2 l)
Minimum outside diameter of
thrust washers:
Max. depth of cut:
Diamond abrasive wheels
Minimum outside diameter of
thrust washers:
Max. depth of cut:
English
25.6 lbs.
(11.6 kg)
28.0 lbs
(12.7 kg)
14 in.
(350 mm)
0.189 in.
(4.8 mm)
0.787 in.
(20 mm)
22 lbf ft
(30 Nm)
4.06 in.
(103 mm)
4.9 in.
(125 mm)
4.06 in.
(103 mm)
4.9 in.
(125 mm)
