USB Client Installation

1. Make sure the power switch is turned off on the computer where you will be
installing the TT8500.
2. Plug the 15-pin connector (HDB15) of the serial cable into the underside of
the TT8500.
3. Plug the USB connector into the port on your host computer.
4. Plug the power adapter plug into the pod on the cable.
5. Plug the AC power supply into a power outlet.
Installation is now complete. You may now turn on your computer. Your TT8500
will auto-configure to USB.
I-6
2. Plug HDB15
connector
into TT8500
Transaction Team™ TT8500
3. Plug USB
connector
into host
4. Plug AC power adapter
into pod
Host
