4 Acquiring CEPH Images
Frankfurt plane
44
8. Ask the patient to swallow any saliva in his/her mouth and remain still with
his/her mouth closed until X-Ray exposure is complete.
9. Click the Ready button after the patient has been positioned. No X-Ray will
be emitted at this point.
10. Proceed to section 4.3 Initiating X-Ray Exposure.
7. The ear rods should fit properly along
the patient's ear canals. The patient's
Frankfurt Plane should be parallel to the
floor.
PaX-i3D Smart(PHT-30LFO) User Manual
