13.1
Restore electrical power to the outlet box by turning the
electricity on at the main fuse box.
Check the operation of the fan by gently pulling on the
light kit assembly pull chain.
Your fan is shipped from the factory with the reversing
switch positioned to circulate air downward. If airflow is
desired in opposite direction, turn the fan off and wait
for the blades to stop turning, then slide the reversing
switch to the opposite position, and turn the fan on
again (Figure 33).
The fan blades will turn in the opposite direction and
reverse the airflow.
Reverse Switch Information
Season Rotation Direction
Summer Counter-Clockwise
Winter Clockwise
13.2
Your fan model is equipped with a 4-position,
3-speed pull chain switch (Figure 34). The operating
sequence is as follows:
Three-Speed
1st Pull—HIGH
2nd Pull—Medium
3rd Pull—Low
4th Pull—OFF

13. Using Your Ceiling Fan

Switch Position
Up
Down
21
REVERSING SWITCH
Figure 33
WARNING
!
To reduce the risk of fire or electrical shock, do not
use this fan with any solid-state speed control device.
LIGHT KIT ASSEMBLY
PULL CHAIN
Figure 34
Please contact 1-800-654-3545 for further assistance
CEILING FAN SPEED
SWITCH PULL CHAIN
emersonfans.com
U.L. Model No.: 52-ANT
