TYROLIT Hydrostress FSE1240 Serie Instrucciones De Servicio página 147

Starter Box Unit #2800215
ITEM PART NO.
1 2800240
2 2800249
3 6011329
2800599
2800200
1800922
4 6011097
2701390
2701392
2800317
2800222
1800923
5 2800224
6 2800245
7 2701870
8 2800552
9 2800312
10 2701274
11 2800299
12 2800400
13 2800401
14 2800402
15 2800403
16 2800248
17 2701267
18 2701871
19 2800315
20 2701299
21 2701295
22 2701066
23 2701307
24 2701273
QTY. DESCRIPTION
1 Enclosure
Subpanel
1
Stop Button Assembly
1
Stop Button Body & Cap
1
1 Contact Block (N.C.)
Stop Label
1
Start Button Assembly
1
Start Button Body
1
1 Contact Block (N.O.)
Green Button Cap
1
1 Clear Protective Boot
1 Start Label
Battery Charge Ammeter
1
1 Reset Button
1 Disconnect Handle
1 Connector, 1/2" Cord
2 Connector, 1" Sealtite Elbow
Rectifier Bridge
1
2 Fuse Holder, 30A-600V Dual
Auxiliary Contact (N.O.)
1
1 Motor Contactor, Siemens
1 Coil, 24V-AC
Overload Relay, 25-100A
1
1 Current Transformer
1 Disconnect Block
1 Disconnect Rod
Grounding Lug
1
1 Transformer, 500VA
Power Relay, 12V-DC
1
1 Fuse, ATQR 10A
1 Fuse, ATMR 25A
2 Fuse, ATQR 4A
