P
1
2
2
Warning:
The screws in the kit are micro-encapsulated and should never to be used more than once.
The micro-encapsulation will become ineffective if they are repeatedly used and the permanent
securing of the screw connection can no longer be guaranteed.
3. Screw the four screws (3, 4) from the installation kit into the adapter, finger-tight only.
4. Now move the seat as far back as possible.
5. Screw both front screws (2) from the installation kit into the seat adapter, finger-tight only.
6. Tightly screw the two front screws (2) using the stipulated torque.
(T30 Torx adapter).
Torque: M8 screws: 25 Nm ± 2 Nm
7. Now move the RECARO seat as far forward as possible.
8. Tightly screw the four rear screws (3, 4) using the stipulated torque (use the T30 Torx adapter).
Torque: M8 screws: 25 Nm ± 2 Nm
Danger:
If the torque is not set correctly, the screws will work loose whilst you are driving.
In this case, the safety concept can no longer be ensured and the vehicle may no longer be used.
The screws must be tightened using the stipulated torque.
RECARO Automotive Seating
1 RECARO seat
2 Front screws - M8 from installation kit
3 Centre screws - M8 from installation kit
4 Rear screws - M8 from installation kit
3
4
