Disconnect the charger from the bicycle´s charging port
While the charger is connected to Rise, the bicycle cannot
tery level at a given time, disconnect the charger from the
bicycle, turn Rise on, and connect it to your Garmin unit
On assemblies with the Shimano displays, disconnect the
charger and power the bicycle on to see the current bat-
Avoid leaving the charger connected to the bike continu-
ously for extended periods of time and charge your bicycle
or battery in a place where you have visual access to it so
the charger can be disconnected if any anomaly is detect-
The RS Smart Charger has been designed to stop charg-
ing the battery when the charge is completed to avoid
recommended to supervise the charge to avoid damages
The lithium-ion batteries are sensitive to temperature dur-
TECHNICAL MANUAL
RS RANGE EXTENDER BATTERY.
The Rise Hydro Smart Charger is not compat-
ible with the Rise Carbon 2021-2022 internal
-
The Rise Carbon 2021-2022 charger is not
compatible with the Rise Hydro internal bat-
To charge the Range Extender, plug the RS charger to the
ed to the charger, the LED on the charger´s body will blink
B LUE PAP ER R I SE · HYDRO 2022
Disconnect the Range Extender connection cable to the
bicycle charging port (in case it is connected) by turning
Extender correctly aligning the connector pins with tho-
body LED will turn blue for 2 seconds and then it will
start fading in and out cyclically until the battery is com-
When the battery is fully charged, the charger´s body LED
-
100%
While the Range Extender is being charged, the charge
ORBEA | 25
When the battery is fully charged, disconnect the charger
from the charging port by carefully pulling from the char-
on the bicycle, connect the Range Extender cable to the
Range Extender and the bicycle charging port with the sa-
fety tabs open and, once the cable is correctly connected,
· Avoid leaving the charger connected to the bike conti-
nuously for extended periods of time and charge your
bicycle or battery in a place where you have visual access
to it so the charger can be disconnected if any anomaly is
The RS Smart Charger has been designed to stop char-
ging the battery when the charge is completed to avoid
recommended to supervise the charge to avoid damages
