0 Technical Specifications - Orbea BLUE PAPER RISE Manual Tecnico

48 | ORBEA

1 0 TECHNICAL SPECIFICATIONS

RISE HYDRO
FRAME MATERIAL
FRONT TRIANGLE
SWINGARM (C/STAYS & S/STAYS)
LINKAGE
INTENDED USE
SIZES
SUSPENSION DESIGN
FORK TRAVEL
MAXIMUM FORK LENGHT (AXLE-TO-CROWN)
FORK OFFSET
REAR TRAVEL
SHOCK MEASUREMENTS (EYE-TO-EYE)
SHOCK HARDWARE
FRONT TRIANGLE
SHOCK YOKE
COIL SHOCK COMPATIBILITY
FOX FLOAT X2 SHOCK COMPATIBILITY
RECOMMENDED SAG
HEADSET
MAXIMUM NUMBER OF HEADSET SPACERS
BOTTOM BRACKET
CHAINLINE
WHEEL SIZE
TECHNICAL MANUAL
Aluminum
S, M, L, XL
Concentric Boost 2 Pivot
140mm (option 150mm)
561mm
44mm
140mm
No
30mm
Shimano EP8 motor axle
B LUE PAP ER R I SE · H YD R O 2022
MAXIMUM TYRE WIDTH (REAR)
MAXIMUM TYRE WIDTH (FRONT)
SPEED SENSOR MAGNET PLACEMENT
REAR AXLE STANDARD
REAR AXLE MEASUREMENTS
REAR AXLE THREAD PITCH
REAR AXLE THREAD LENGTH
SEATPOST DIAMETER
SEATPOST CLAMP DIAMETER
MAXIMUM SEATPOST INSERTION
S
M
L
XL
DROPPER SEATPOST INTERNAL CABLING
COMPATIBLE
FRONT DERAILLEUR
COMPATIBLE CHAINRINGS
MAXIMUM CHAINRING SIZE
MINIMUM CHAINRING SIZE
COMPATIBLE OVAL CHAINRING
BRAKES
* Not all calipers and rotors in the market are compatible with all frames.
befores purchasing.
Depends on fork
6-bolt rotors: 6-bolt Orbea magnet
Centerlock rotors: Integrated magnet rotors or Orbea centerlock
magnet adaptor
Boost 12x148
12x187mm
15mm
35mm
225mm
260mm
280mm
290mm
34T
30T
No
Disc*
ORBEA | 49
E N
