Installation
3
Attach your UPS mounting brackets
holes E of the UPS using the included hardware
mounting bracket "ears" should face forward.
It is recommended you remove the UPS internal batteries prior
to installation. Doing so will remove excess weight and allow for
safer handling.
Note: To remove battery pack trays inside the UPS, refer to Internal
Battery Rotation.
4
With the aid of an assistant, lift your UPS and slide it into the shelves. Attach the UPS mounting ears to the front mounting rails with
user-supplied screws and washers
Note: To install battery trays inside the UPS, refer to instructions 5-8 in the Internal Battery Rotation section within the Installation section of this
manual.
PDM Outlet Configuration will Vary by Model
4
D to the forward mounting
F . The
. Tighten all screws securely.
