GASTER N 119 ÷ 289 AW

4.3 Technical data table

MODEL
Number of elements
Max. heating capacity
Min. heating capacity
Max. Heat Output in heating
Max. Heat Output in heating
Efficiency Pmax (80-60°C)
Efficiency 30%
Efficiency class Directive 92/42 EEC
NOx emission class
Burner nozzles G20
Gas supply pressure G20
Max gas pressure at burner G20
Min. gas pressure at burner G20
Max. gas delivery G20
Min. gas delivery G20
Burner nozzles G25
Gas supply pressure G25
Max. gas pressure at burner G25
Min. gas pressure at burner G25
Burner nozzles G31
Gas supply pressure G31
Max gas pressure at burner G31
Min gas pressure at burner G31
Max. gas delivery G31
Min. gas delivery G31
Max. working pressure in heating
Min. working pressure in heating
Max. heating temperature
Heating water content
Protection rating
Power supply voltage
Electrical power input
Type of unit
PIN CE

4.4 Diagrams

Pressure loss
EN
119 136
8 9
kW 131.0 149.0
kW 77.0 89.0
kW 119.0 136.0
kW 71.0 82.0
% 91.2 91.3
% 92.3 92.2
** **
1 1
no. x Ø 7x3.40 8x3.40
mbar 20 20
mbar 13.3 13.3
mbar 4.8 4.8
m /h 13.80 15.80
3
m /h 8.10 9.40
3
no. x Ø 7x3.80 8x3.80
mbar 25 25
mbar 14 14
mbar 5 5
no. x Ø 7x2.15 8x2.15
mbar 37 37
mbar 36 36
mbar 11.4 11.4
kg/h 10.26 11.66
kg/h 6 6.9
bar 6 6
bar 0.3 0.3
°C 95 95
litres 38 42
IP X0D X0D
V/Hz 230/50 230/50
W 40 40
cod. 3541F272 - Rev. 00 - 06/2018
153 170 187
10 11 12
168.0 187.0 206.0
100.0 110.0 122.0
153.0 170.0 187.0
92.0 102.0 112.0
91.4 91.5 91.6
92.2 92.1 92.1
** ** **
1 1 1
9x3.40 10x3.40 11x3.40
20 20 20
13.3 13.3 13.3
4.8 4.8 4.8
17.90 19.80 21.80
10.60 11.60 12.90
9x3.80 10x3.80 11x3.80
25 25 25
14 14 14
5 5 5
9x2.15 10x2.15 11x2.15
37 37 37
36 36 36
11.4 11.4 11.4
13.2 14.64 16.31
7.8 8.6 9.5
6 6 6
0.3 0.3 0.3
95 95 95
46 50 54
X0D X0D X0D
230/50 230/50 230/50
80 80 80
B
11
0085BM0382
221 255 289
14 16 18
243.0 280.0 317.0
144.0 166.0 188.0
221.0 255.0 289.0
133.0 153.0 173.0
91.7 91.9 92.0
92.0 91.9 91.7
** ** **
1 1 1
13x3.40 15x3.40 17x3.40
20 20 20
13.3 13.3 13.3
4.8 4.8 4.8
25.70 29.60 33.50
15.20 17.60 19.90
13x3.80 15x3.80 17x3.80
25 25 25
14 14 14
5 5 5
13x2.15 15x2.15 17x2.15
37 37 37
36 36 36
11.4 11.4 11.4
19 21.92 24.82
11.2 12.9 14.60
6 6 6
0.3 0.3 0.3
95 95 95
62 70 78
X0D X0D X0D
230/50 230/50 230/50
80 80 80
fig. 20 -
33
