and Fig. 15 page 61).
EN
Fig. 16 - Side panel insertion
• Insert from on high the metal side panels on the appropriate guides getting it slightly course all the way
(see Fig. 16 page 62).
• Insert from on high the ceramic side panels on the appropriate guides getting it slightly course all the
way (see Fig. 17 page 62).
• The narrow side panel is to clasp on the squared holes (see Fig. 18 page 62).
• Recompose all.
9.5

ELECTRIC CONNECTION

• The electric connection occurs through a cable with plug put in an electric socket which is able to
support charge and tension specific of every model, as described in the technical datas table (see
FEATURES page 88).
• The plug must be easily accessible when the appliance is installed.
62
Fig. 18 - Coloured side panel insertion
Warning: the appliance must be installed by an authorized technician!
The cable must not get in touch with the fume exhaust pipe and nor with every other
part of the stove.
Fig. 17 - Ceramic panel insertion
NICE - MIRIAM - CRISTAL - LEONORA - PRETTY - DIANA - KRISS - MARY
