the welding position and the type of joint to be made.
Always remember to shut off the machine and remove
the electrode from the clamp after welding.

3.3 TIG WELDING

• This welding machine is suitable for welding the following
materials using the TIG procedure: stainless steel, iron, cop-
per.
• Make sure that the switch (F) is in position 0.
• Connect the mass cable connector to the positive pole (+)
of the welding machine, and the clamp to the workpiece as
close as possible to the welding point.
• Use the torch type T150 (art. 1567.01) and connect the
power connector to the negative pole (-) of the welding
machine.
• Connect the gas hose to the outlet of the pressure regula-
tor, connected to an ARGON cylinder.
. Press the torch trigger and adjust the gas flow.
• Inside the torch is a valve that blocks the gas flow when
the trigger is released.
. Use a 2% thorium-covered tungsten electrode (red strip),
diameter 1.6 (1/16").
• Do not touch the electrode and mass terminal simulta-
neously.
• Turn the machine on using the switch (F).
• Adjust the current, then press the torch trigger to allow gas
to escape.
• Strike the arc by contact using a firm, rapid stroke.
• Remember to shut off the machine and close the gas cylin-
der valve when you have finished welding.
4 ERRORS AND SOLUTIONS
ERROR
PROBABLE CAUSE
The welding
Switch set to 0
machine does
not deliver
Mains fuses burnt.
them.
current.
Completely
Plug not correctly
inoperative.
inserted in the
power socket.
The welding
Incorrect supply
machine does
voltage: yellow
not deliver
lamp lit.
current, but the
fan works.
Thermostat open:
yellow lamp lit.
SOLUTION
Set it to 1.
Replace
Insert the plug.
See 2.3
Wait approxima
tely 5/6 min.
See 2.3
7
