FUEL SYSTEM

The engine is fitted with a dual master mixer assembly
carburetion system, which allows it to run on either NG or
LPG. It has been configured at the factory to run on NG. If your
installation requires the engine to run on LPG, orifices in the
master mixer assembly carburetor must be changed.

BATTERY REQUIREMENTS

Two (2) 12 volt Group U1 batteries with a minimum of
350 CCA each. Battery size: 7
(196mm L x 131mm W x 185mm H). This is based on testing
in extreme cold and heat -22° F (-30° C) to 104 ° F (40° C).
Purchase batteries locally. Install positive cable first.
Install a cable from the positive (+) terminal of one battery to the
negative (–) terminal of the other battery. Always connect the
positive (+) battery cable to the generator first. (Figure 8)
2
To Ground
!
For battery installation, maintenance, and safety
requirements refer to purchased manufacturer battery
installation and safety manual.
© 2015 Champion Power Equipment
All manuals and user guides at all-guides.com
L x 5 W x 7 H inches
3/4 3/16 5/16
1
Figure 8
U1 battery post style
CAUTION
GENERAL INFORMATION

BATTERY CHARGING

The generator is equipped with an automatic battery charger. The
charger will sense the battery's state of charge and automatically
charge the battery when required. LED lights on the charger display
the battery state of charge. See Figure 7 on page 19.

MODEL AND SERIAL NUMBER

The model and serial number plate is affixed to the generator
above the control panel. Have this information if calling for
service or ordering parts. (Figure 9)
To Starter
Model 100199
Figure 9
