3 Scope of delivery

• 1x Assembly instructions
• 1x Pressure regulator (see: order)
If you have configured your product with optional elements, these elements
are already assembled on the product.
• For product versions 614357F, 614357G, 614359F, 614359G:
1x 7-pin M16 cable socket, 833-064004
• For non-ATEX product version: 1x declaration of conformity
• For ATEX product version: 2x declaration of conformity

4 Transport and storage

4.1 Transporting the product

Hazards during transportation
• Proceed with caution and observe the information on the packaging when un-
loading and transporting the packaged product to the destination.
• Ensure that the product cannot fall down before the product is released from
the mountings.
• Take steps to avoid damage when lifting the product.
• Wear PPE.

4.2 Storing the product

Damage due to incorrect storage
Unfavorable storage conditions can result in corrosion and material deteriora-
tion.
• Only store the product in locations which are dry, cool, and prevent corrosion.
• Protect the product from direct sunlight and UV radiation.
• Keep the product in its packaging until the time of installation.
• Also observe any additional storage information on the product packaging.
Elastomer parts
Pneumatic components typically have elastomer seals that are subject to a con-
stant process of aging.
• Products that have been stored for longer than 2 years have a shorter service
life.
• The aging process can be accelerated by heat and light (UV rays).
If you are unsure about the status of the elastomer seals, Get in touch with our
contact address. See back cover.
Compressed air connections
• Ensure that all compressed air connections are protected against contamina-
tion by protective caps.
• Tape open compressed air connections or provide them with suitable protec-
tive caps.

4.3 Returning the product

• Before returning the product: Get in touch with our contact address. See back
cover.
• Observe the storage conditions until such time as you return the product.

5 Product description

5.1 Brief description

The Sentronic PLUS pressure regulator is a digital electronic pressure regulator.
The pressure regulator is designed for various output pressures.
The product is used for the following tasks:
• Changing pressures electrically
• Adjusting pressures remotely
The product is factory calibrated.
AVENTICS™ Sentronic PLUS 614 | IM14229-R06 | English

5.2 Labeling and identification

CE mark and UKCA identification
This product meets the requirements of directive 2014/34/EU (EMC) and
directive 2014/30/EU (ATEX). The product is labeled with CE and UKCA
identification. The declaration of conformity is enclosed.
Product identification
The ordered product is clearly identified by the material number. The material
number can be found in these locations:
• On the name plate.

5.2.1 Configuration of the material number

Sentronic PLUS – digital electronic pressure regulator
6 1 4 3 5 7 B
Sentronic PLUS – with external pneumatic pressure connection
6 1 4 3 5 9 B
B
Control panel
A M12 without display – not explosion-protected
D M12 with display – not explosion-protected
E M12 without display – explosion-protected (ATEX)
F M16 electrical connector, 7-pin, with display – not explosion-protected
G M16 electrical connector, 7-pin, without display – not explosion-protected
A
Version (connection), housing
0 NG6 (G 1/4), aluminum
1 NG12 (G 1/2), aluminum
2 NG20 (G 1), aluminum
3 NG6 (ISO 1), aluminum
4 NG6 (NPT 1/4"), aluminum
5 NG12 (NPT 1/2"), aluminum
6 NG20 (NPT 1"), aluminum
S
Set point
0 0 ... 10 V
1 0 ... 20 mA
2 4 ... 20 mA
I
Actual value
1 Actual value output 0 ... 10 V
2 Actual value output 0 ... 20 mA
3 Actual value output 4 ... 20 mA
4 Actual value input 0 ... 10 V
5 Actual value input 0 ... 20 mA
6 Actual value input 4 ... 20 mA
D
Digital output
1 Pressure switch output
PNP ±5 %
PP
Pressure range
Relative pressure
40 0 ... 100 mbar
50 0 ... 500 mbar
60 0 ... 1 bar
02 0 ... 2 bar
03 0 ... 3 bar
05 0 ... 5 bar
A S I
A S I
7 NG3 (G 1/8), brass
8 NG6 (G 1/4), brass
9 NG3 (NPT 1/8), brass
A NG6 (NPT 1/4"), brass
C NG6 (G 1/4), VA
2)
H NG6 (G 1/4), brass
3)
3)
3)
Max. input pressure
Vacuum (relative)
(MAP) [bar]
0.2 V3 = 0 ... -1 bar shut-off
version
1
2
3
7
8
D PP
D PP
