Intended Use; General Safety Information - Klafs 16043 Instrucciones De Operación

2.

Intended Use

The Softclima Control System 16043 is exclusively intended for the control of approved (registered by
the Klafs with VDE or TÜV) sauna heaters and automatic evaporators (intended use).
Any other use is considered not in accordance with the terms of usage! The manufacturer is not
responsible for damage resulting from other forms of usage; the user alone carries this risk. Proper and
intended use and operation include compliance with the requirements for assembly, operation,
maintenance and repair stipulated by the manufacturer.
The Softclima Control System 16043 may only be operated and maintained by persons, who are
familiar with its usage and informed of the dangers involved. Follow the relevant German VDE
regulations as well as other generally recognized safety rules. Damage resulting from arbitrary
changes to the control system are excluded from the manufacturer's liability.
3.

General safety information

Read and observe the operating and safety instructions before start-up!
In these operating instructions all text passages concerning your safety are marked with
this symbol. Pass all safety instructions on to other users.
d
Before opening the control system housing remove the power from the control system!
d
The control system may be connected to mains by a locally authorized electrician only!
d
Sauna installations may be connected to mains with a fixed connection only according to VDE
regulations. In the connecting feed line use a residual-current breaker (RCB) I
min. 3 mm contact opening.
d
Inform Klafs Customer Service of problems that a certified electrician cannot repair!
d
Only use original Klafs spare parts!
d
Arbitrary changes to the control system are not allowed!
d
Install the control system, in accordance with the assembly instructions!
d
Electrical wiring within the cabin and the cabin walls must have silicone insulation.
d
Before activating the control system always make sure that no inflammable objects are on or near
the sauna heater. FIRE RISK!
d
Do not use the sauna to dry your laundry!
d
Never pour concentrated aromatic oils or extracts directly onto the sauna heater. Only use the
indicated concentration (approx. 20 ‐ 30 drops to 1 liter of water)!
d
Never pour herbal extracts, as used in Softclima mode, directly into the evaporator. Outside of
the cabin, fill the fragrance bowl a quarter full with water and add the herbal extracts drop by
drop in accordance with the instructions on the bottle. Then re-attach the fragrance bowl to the
steam exit!
d
As infusion agent it is only permissible to use Klafs' aromatic extract!
d
Never store the bottle containing aromatic oils or infusion agent in the sauna cabin!
d
Regularly check the sauna heater for damage.
PAGE 6
Softclima
v 0.03 A with
nN
5070145/05.09
