Activating the shaker

Activate the shaker to help separate the earth from the
crop.
Carry out the operations described.
1) Loosen the knob (A).
2) Use the lever (B) to activate the shaker.
The more the lever is rotated, the stronger the shak-
ing action and vice versa.
3) Tighten the knob (A).

Unhitching the machine from the tractor

D
UN41-0830LR
Carry out the operations described.
1) Select an area with flat, solid ground to park the work
vehicle.
2) Using the tractor's controls, lower the work vehicle to
the ground.
3) Switch off the engine, remove and keep the ignition
key.
4) Disconnect the driveshaft from the tractor's PTO.
English language
INFORMATION FOR USE
UN41-0829LR
C
B
5) Take out the lock pin (A) and remove the pin (B).
6) Take out the lock pin (C) and remove the pin (D).
7) Repeat the same procedure to slide the other pin
18
B
A
out.
6
-
+
A
Use and maintenance
