SPRAYHEAD VALVE, WATER BY-PASS VALVE & SPRAYHEAD
ITEM
PART NO.
1
12422.0005
2
12422.0008
3
12422.0008
4
35052.0000*
5
32591.0006*
6
27370.0003
27370.0005
27370.0004
00970.0000
7
- - - - - - - -
8
- - - - - - - -
9
- - - - - - - -
10
- - - - - - - -
11
23255.0000
12
- - - - - - - -
13
34956.0000
14
26846.0000
26846.0002
26846.0001
15
22305.0000
22305.0002
22305.0003
23254.0000
16
23256.0000
17
- - - - - - - -
18
- - - - - - - -
19
23255.0000
20
- - - - - - - -
21
32591.0003*
22
34801.0001
23
01075.0000
24
34868.0000
25
35070.0001
26
34867.0004
27
32591.1001
32591.1002
28
35052.1000
29
11517.0008
30
35308.1004
* Indicates the part number listed is for reference only. See DESCRIPTION for possible service replacement.
QTY.
DESCRIPTION
3
Clamp, Hose .62"/.71" I.D.
1
Clamp, Hose .93"/1.10" I.D.
1
Clamp, Hose .93"/1.10" I.D.
1
Tube, Silicone .75" I.D. x 1.0" O.D. x 6.25" (Order item 28)
1
Tube, Silicone .50" I.D. x .75" O.D. x 6.50" (Order item 27)
1
Valve Assy, Bypass 120V (Includes items 7 thru 12)
1
Valve Assy, Bypass 230V (Includes items 7 thru 12)
1
Valve Assy, Bypass 200V (Includes items 7 thru 12)
2
Nut, Keps #8 - 32
1
Coil Assy, Bypass Valve
1
Bracket, Mounting
1
Spring (Not available order item 30)
1
Plunger (Not available order item 30)
1
Diaphragm
1
Body (Not available order item 6)
1
Fitting, .250" NPT x .75" I.D. Hose
1
Valve Assy, Sprayhead 120V (Includes items 15 thru 20)
1
Valve Assy, Sprayhead 230V (Includes items 15 thru 20)
1
Valve Assy, Sprayhead 200V (Includes items 15 thru 20)
1
Coil Assy, Valve 120V
1
Coil Assy, Valve 230V
1
Coil Assy, Valve 200V
4
Screw, #8 - 32
1
Spacer Plate
1
Spring (Not available order item 29)
1
Plunger (Not available order item 29)
1
Diaphragm
1
Body (Not available order item 15)
1
Tube, Silicone .50" I.D. x .75" O.D. x 1.10" (Order item 27)
1
Fitting, Bypass Restrictor
1
Nut, Hex .438" - 20
1
Seal, Sprayhead
1
Sprayhead Back
1
Sprayhead
1
Tube, Silicone .50" I.D. x .75" O.D. x 12.0"
1
Tube, Silicone .50" I.D. x .75" O.D. x 36.0"
1
Tube, Silicone .75" I.D. x 1.0" O.D. x 12.0"
-
Solenoid Valve Repair Kit, Bypass & Sprayhead (Includes one
each of spring, plunger and diaphragm)
-
Sprayhead Assy (Includes one each of items 24 - 26)
Refer to item 30
17
Not illustrated
36096 070512
