ENGLISH
8
Operation
This model is equipped with automatic mechanical bypass and humidity sensor, which prevents the equipment
from going to Vmax after exceeding a threshold value. See "Use" section for all the functions of the appliance.
HMI installation - remote control display
The remote control does not need to be powered to the external power supply but
is wired directly to the target product (via terminal board). Connection via cable is carried out with a
subsurface tube (recessed).
WARNING: The installation of the flush-mounted box for the
!
remote control display must only be carried out by professionally
qualified personnel.
Structure and equipment of remote control display (fig. 8A):
- (1) No. 1 Plaque.
- (2) No. 1 Remote control unit (pre-assembled on support).
- (3) No. 1 Subframe
- (4) No. 1 Standard electrical box (not supplied).
- Supplied screws.
71
